No. 3617 230V Powered Combination Rotary Machine

$8,506.00

A versatile machine designed for deep throat (up to 13″) beading, crimping, and other roll operations up to 18 gauge material. Back-geared, with steel horn, bronze bushed bearing and one-piece frame. Mounted on floor stand with adjustable motor mount, “V” belt drive, and 230V, 3/4 hp. geared head motor. Unit includes gauges and spacing collars for all operations except flanging.?Rolls ordered separately.

Additional information

Weight 475 lbs
Maximum capacity, mild steel

18 ga./1,25mm

Throat Depth

13in./330mm

Distance between shaft centers

3in. /76.2mm

Ratio gearing

3-1/2 : 1

Motor (230 or 460v, 3ph)

3/4 h.p.
