Eckold Kraftformer KF 340

The KF 340 is one of the medium-sized machines from Eckold. Because of the smaller size and wide range of tools, the KF 340 is the perfect all-rounder for any shop. With a horizontal throat of 13.4″ (340 mm), the KF 340 is capable of working large components up to 9 gauge (.16″ / 4 mm) material thickness.

SKU: 021.013.0000 / 021.013.5000 / 021.013.6000 Categories: ,

Description

Eckold Kraftformers are multi-functional sheet metal forming machines. Tooling options for shrinking, stretching, doming, planishing, flattening and more. Kraftformers can be used in a variety of functions because of their refined design and vast tooling options. The combination of different forming operations in one device saves space and increases efficiency. The smart design allows for upgrading the machine anytime. They are modular, efficient and high quality thus the choice for industry professionals. Power Hammer Shrinker Stretcher

The KF 340 is one of the medium-sized machines from Eckold. It combines strength and durability with power, precision control and is characterized by a modern design. The control system display visualizes operations, fault tracing and maintenance rates thus ensuring optimum machine performance. All forming tools have a quick change design which eliminates down time. Because of the smaller size and wide range of tools, the KF 340 is the perfect all-rounder for any shop. With a horizontal throat of 13.4″ (340 mm), the KF 340 is capable of working large components up to 9 gauge (.16″ / 4 mm) material thickness. because

View Tooling Catalog

Start Your Quote

Eckold is a leader for cold forming shrinking and stretching technology because they offer an unrivaled range of standard tools and custom solutions. These machines convince their users in the sheet metal forming or finishing work because they’re precise, simple and durable.because Power Hammer Shrinker Stretcher because

Additional information

Weight 1335 lbs
Dimensions 49 × 30 × 69 in
Forming Capacity

Aluminum (Rm = 250N/mm2) – 9 gauge/ .157"/ 4.0 mm
Steel (Rm = 400N/mm2) – 12 gauge/ .118"/ 3.0 mm
Stainless Steel (Rm = 600N/mm2) – 14 gauge/ .078"/ 2.0 mm

Horizontal Throat Depth

13.39" (340 mm)

Vertical Throat Height

9.47" (245 mm)

Upper Ram Adjustment

1.18" / 30mm

Drive

Electric

Stroke Frequency

Continuous Stroke

Strokes Per Minute

250 – 550
